8x8/ 16x16/ 36x36 inputs and outputs
HDMI, DVI-U (DVI/VGA/YPbPr/CVBS), VGA, 3G/HD/SD-SDI, HDBaseT and optical fiber
Seamless switching without image tear, black-screen or flicker
Gen-Lock videowall technology
Redundant dual-power design
Works easily with an Ethernet switch, no configuration is required
Plug and play
Supports visual control through a tablet/cellphone.
Easy to build an IP matrix or a video wall easily.
Independent RS232 routing.
Up to 4K60Hz (4:4:4), 18Gbps video bandwidth, HDMI 2.0b, HDCP 2.2
Audio formats LPCM 2.0CH 48kHz
Transceiver design of encoder and decoder, fiber and copper dual-mode
Images roaming: a unit as a decoder can process up to 16 signals, enabling arbitrary windowing, roaming, overlaying, and videowall
Supports KVM
Universal H.264/265 protocol, supporting IPC access and seamless integration with security cameras
Support high-definition background image (both video and picture are available), as well as multi-screen videowall
Support scrolling subtitles and character overlay
Support point-to-point signal extension
Support signal distribution, multicast mode, matrix, and video wall functions over a 1G Network Switch
Integrated central control over RS-232, APP on portable devices available
Support user rights management
Flexible control via KVM, APP, and Control Server
Standard POE supported (802.3af Class 3, PD mode)
The encoder supports HDMI loop-out
The encoder supports audio embedding and de-embedding
Comprehensive visual interaction mode, signal source, large screen status, scene preview, and environmental visualization control
Both Input and output video resolution is up to 4K60 4:4:4
Integrate both Copper and Fiber ports redundancy
Dante enabled
Support unicast and multicast functions
Support videowall
Support 18Gbps video bandwidth, HDCP 2.2 and DP 1.2
Input and output video resolution is up to 4K60 4:4:4
Signal transmission distance can be extended up to 328ft/100m via CAT6/6A/7 cable
Transmit video, analog audio, RS-232, CEC and USB signal over Ethernet
Support USB 2.0 and KVM function
US 2-Gang wall-plate
With HDMI and USB-C dual inputs, supporting auto-switching and manual switching modes
The USB-C 1 port supports video/audio/USB data transmission and power charging.
Audio embedding and de-embedding are supported
Dante AV-A mode is supported
Support unicast and multicast functions
Support point-to-point, video matrix, and video wall functions (video wall supports up to 9x9)
Built-in MJPEG Substream for video real-time preview on portable devices
Support 1G Ethernet Switch, router and hub device transmission
Standard PoE (802.3at PD device) or local 12V power supply
Built-in web page configuration and control, Telnet and SSH as well
Support HDR10, Dolby Vision, HLG bypass
Flexible control via Web GUI/TCP/RS-232 and third-party central control
SDVoE 4K60 AV over IP Transceiver with Fiber
Support video resolution up to 4k2k@60Hz 4:4:4
Flexible transceiver design (Encoder, Decoder, Copper port, and Fiber port share a box)
Support signal extension, matrix, seamless switching, Video Wall, and up to 32 windows Multi-viewer
Built-in H.264/265 preview module for video live preview
1x standard 3G/HD/SD SDI signal input
4x standard 3G/HD/SD SDI signal outputs
SDI input signal auto-detected.
SDI Jitter clean
Supports 3G SDI Level A and B
Single-image, Dual-image PIP, Dual-image POP, Quad-image split view
DIP switch to setup output resolutions
Seamless switching without any black screen intervals
Auto-cycle of single-image modes
With network control software
Support 1-CH HDMI to 2-CH SDI outputs
Support 3G/HD/SD SDI signal output
Input and output resolution adaptive, output up to 1080P60Hz
TYPE C(5V) power supply
Support both Level A and Level B outputs
Support 3G/HD/SD SDI signal input
Input and output resolution adaptive, output up to 1080P60
Support 1-CH HDMI output
Support 1-CH SDI loop out
TYPE C (5V) power supply
48Gbps FRL and 18Gbps TMDS video bandwidth
Resolution up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit
HDR, HDR10, HDR10+, Dolby Vision, HLG pass-through
Support audio de-embedding function
Support resolution auto downscaling on each output
1x4 HDMI 18Gbps Splitter w/ 150m HDBaseT
HDMI 2.0b, HDCP 2.2 and HDCP 1.x compliant
Support video resolution up to 4K2K@60Hz 4:4:4
120 meters at the resolution of 4K2K@60Hz
150 meters at 1080P@60Hz
