Support FULL NDI, codec

Encoder and Decoder all-in-one design.

The encoder supports the HDMI loop-out

The HDMI input resolution is as 1080P/60, 1080P/59.94,1080P/50, 1080P/30, 1080P/29.97, 1080P/25, 1080P/24, 720P/60, 720P/50

Support PoE power supply

Support PTZ camera control

Support TALLY light display

Support audio embedding and de-embedding

Can be configured via the WEB GUI

Support Multicast

4xHDMI 2.0 inputs, 2xHDMI 2.0 outputs,1xHDMI 2.0 loop out, all up to 4K@60Hz 4:4:4.

Display and control 4 input sources with only one mouse and keyboard set.

Play-and-Play, no need for control software

Adjust the input window size and switch signals by mouse and keyboard.

The position and size of the 4 input windows can be adjusted arbitrarily.

Multiple display layouts include quad-view, triple-view, dual-view, and full view.

Quad-view for 2 duplicate outputs or dual-view for 2 different outputs.

External USB devices like a printer, webcam, microphone, and speakerphone can be shared by 4 PCs at the same time via the front USB ports.

Each video window supports free overlay, resize, move and overlap.

Inputs and outputs support resolutions up to 4K@60Hz 4:4:4 8-bit.

Supports HDCP 2.3 and is backward compatible.

HDMI outputs support free scaler from 480p to 2160p, and provide seamless transition without seeing black screen switching.

Full-featured USB-C input port, supports 4K@60Hz, USB 3.1 gen1, 1G network, and PD 3.0 charging up to 60 watts.

Supports USB host switching and USB device extension.

Switching USB hosts include 1x USB3.0 type-C port and 2x local USB3.0 type-B ports;

USB devices include 4x local USB 3.0 type-A ports.

Versatile audio connection and DSP.

2x Mic inputs, and 1x LINE input

1x USB audio input and 1x USB audio output, with 48KHz sampling frequency

Dante 4x4 with various sampling rates

HDMI audio de-embedding with sampling frequency up to 192KHz

Supports 2x balanced audio outputs.

Multi-Channel audio DSP Processing—simultaneously processing audio input and output signals, including gain, EQ, etc.

Supports GPIO control and relay control.

Multiple control options, including front panel buttons, RS-232, and LAN (Web UI &Telnet).

Resolution 4K@60Hz (4:4:4)

High-Quality Connectors - 24K gold−plated connectors resist corrosion and offer the best possible connectivity.

Supports HDMI Ethernet

Supports ARC (Audio Return Channel)

Super-soft design.

Varied Selection of Lengths - Available in versions of 1m, 2m, 3m, 5m, 7m and 10m.

4 windows (layers) on each display

4K60Hz signal input

Multiple video wall groups (up to 4x video walls)

Signal preview and monitoring

High-resolution background image

Scrolling text function

US 1-Gang wall plate

Extension of USB 3.2 Gen 1 up to 100m/328ft over CAT6a cable

USB 3.2 Gen 1 connectivity with data transfer rate up to 5Gbps

Backwards compatible with USB 2.0 and 1.1

Hardware acceleration for isochronous and bulk transfer

TX features 1x USB-B and 1x USB-C selectable host ports

Supports auto-switching and manual-switching modes

Supports RS-232 pass-through and API control

Supports firmware upgrade via USB-C service port

Support FSYNC GPIO pass-through for industry camera

RX features 1x USB-C and 3x USB-A output ports (2x 5V@1A and 2x 5V@1.5A)

Plug-and-play with no drivers or software download required

Support bi-directional 24V PoC (Power over Cable)

Extension of USB 3.2 Gen 1 up to 100m/328ft via CAT6a cable
USB 3.2 Gen 1 connectivity with data transfer rate up to 5Gbps
Backwards compatible with USB 2.0 and 1.1
Hardware acceleration for isochronous and bulk transfer
TX features 1x USB-B and 1x USB-C selectable host ports
Support auto-switching and manual-switching modes
RX features 1x USB-C and 3x USB-A output ports (2x 5V@1A and 2x 5V@1.5A)
Support RS-232 pass-through and API control
Supports firmware upgrade via USB-C service port
Support FSYNC GPIO pass-through for industry camera use
Supports bi-directional 24V PoC (Power over Cable)
Plug-and-play with no drivers, downloads, or software required

Video resolution up to 4K@60Hz 4:4:4

Compliant with HDMI 2.0b, HDCP 2.2, and DisplayPort 1.2a

Supports 18Gbps video bandwidth

Support HDMI and USB-C input

Distance up to 230ft / 70m for 1080P or 131ft / 40m for 4K via a single CAT6/6a/7 cable

Support HDR10 and HDR10+

Audio formats support Dolby Atmos, TrueHD, Digital+, Digital; DTS X, HD Master Audio, HD High Resolution Audio, 5.1; PCM 2-8Ch

Input signal selection supports automatic mode and manual mode

USB2.0 extension with Receiver

Support PoE function (only from Receiver to Transmitter)

With USB-C charging port

US 1-gang version

Available in white color

Video resolution up to 4K2K@50/60Hz 4:4:4

Compliant with HDMI 2.0b, HDCP 2.2, and Display Port 1.2a

HDMI input supports 18Gbps video bandwidth;

USB-C input supports 5.4Gbps video bandwidth

Distance up to 230ft / 70m for 1080P@60 or 131ft / 40m for 4K@60 via a single CAT6/6a/7 cable

Support 3D, HDR10 and Dolby Vision

HDMI audio formats support LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, and DSD

Support HDMI and USB-C input

With USB-C charging port

US 1-Gang version

Input signal selection supports automatic mode and manual mode

Support PoE function (only from Receiver to Transmitter)

Available in white color

The receiver is included

Resolution up to 4K2K@60Hz 4:4:4

HDBaseT 2.0

Compliant with HDCP 2.3, 18Gbps video bandwidth

4K60/4K30/1080P signal transmission distance up to 328ft/100m via a single CAT6A/7 cable (HDBT Standard Mode)

1080P 8bit signal transmission distance up to 492ft/150m via a single CAT6A/7 cable (HDBT Long Reach Mode)

USB-C and HDMI signal inputs support auto or manual switching mode

Auto switching supports HDMI 5V or signal detection

USB-C supports DP-ALT mode for A/V, USB 2.0 data, and power charging up to 60 watts

TX/RX USB-A client ports VBUS on or off depending on whether the USB host is connected or not

HDR, HDR10, HDR10+, Dolby Vision LLM and HLG pass-through

4K to 1080p downscaling features on HDMI output, no frame rate conversion

Both TX and RX support analog audio de-embedding

RS-232 signal pass-through and guest-mode control

Support bi-directional IR signal pass-through, USB 2.0 signal transmission

Advanced EDID management

TX USB-A ports provide power up to 500mA, RX USB-A ports offer power up to 1000mA

Support bi-directional 24V POC

Support video resolution up to 4K2K@60Hz (4:4:4)

HDMI 2.0b, HDCP 2.2/1.x, and DP 1.2a compliant

HDMI input supports 18Gbps video bandwidth

Up to 7.1 channels of HD audio

Input signal source selection supports button switching

HBT mode: Audio and video signals can be transmitted up to 100m for 4K60/4K30/1080P

LRM mode: Audio and video signals can be transmitted up to 150m for 4K30/1080P

Built-in EDID DIP switch supports intelligent EDID management

Built-in audio DIP switch supports analog audio embedding

Built-in POC

Transmit bidirectional Infrared control signal together with the HDMI signal.

Transmit bidirectional RS-232 control signal together with the HDMI signal.

The Receiver supports USB 2.0 signal transmission

Standard UK version wall box

USB 5Gbps 4x4 Matrix

Enables 4 computers to share 4 USB 3.2 Gen 1 devices

USB 3.2 Gen 1 compliant, data transfer rates up to 5Gbps

LED indicates which host is active

Over-current protection

5V/1.5A output for USB device ports

USB device ports compliant with USB 3.2 Gen 1, USB 2.0, and USB 1.1

Plug and Play – no drivers or external power adapter needed

Multi-platform support – Windows, Linux and Mac

Control via front panel buttons, IR remote, RS-232, and Web GUI

Support 18Gbps video bandwidth, HDCP 2.2 and DP 1.2

Input and output video resolution is up to 4K60 4:4:4

Signal transmission distance can be extended up to 328ft/100m via CAT6/6A/7 cable

Transmit video, analog audio, RS-232, CEC and USB signal over Ethernet

Support USB 2.0 and KVM function

US 2-Gang wall-plate

With HDMI and USB-C dual inputs, supporting auto-switching and manual switching modes

The USB-C 1 port supports video/audio/USB data transmission and power charging.

Audio embedding and de-embedding are supported

Dante AV-A mode is supported

Support unicast and multicast functions

Support point-to-point, video matrix, and video wall functions (video wall supports up to 9x9)

Built-in MJPEG Substream for video real-time preview on portable devices

Support 1G Ethernet Switch, router and hub device transmission

Standard PoE (802.3at PD device) or local 12V power supply

Built-in web page configuration and control, Telnet and SSH as well

Support HDR10, Dolby Vision, HLG bypass

Flexible control via Web GUI/TCP/RS-232 and third-party central control

HDMI 2.0b, HDCP 2.2, and HDCP 1.x compliant

Support 18Gbps video bandwidth

Input and output resolutions support up to 4K2K@60 4:4:4

Support LPCM, AC3, DD+, DTS, DTS-HD, up to 7.1 audio channel

Seamless switching between input channels and combined multiple images on a single UHD monitor

Up to 4 display modes: SINGLE, PIP, PBP (1), PBP (2)

Audio de-embedding via analog and optical fiber audio ports

Support volume control and independent audio selection

Advanced EDID management

Control via front panel buttons, IR remote, RS-232 commands

Compact design for easy and flexible installation

1080P60 H.264/265 HD Encoder

Video resolution up to 1920x1200@60Hz 4:4:4

Supports three streams: 1080P60Hz H265 + 540P@30 H264 +1280*720@5 JPEG

Supports RTSP/UDP, RTSP/TCP, RTP/UDP, TS/UDP, RTMP/RTMPS stream standards

Main stream output: 1080P60Hz

Second stream output: 540P30Hz

Supports unicast and multicast

Supports audio-only stream and audio delay settings

Supports streaming control (play/pause/stop )

Supports bitrate/resolution/frame rate/EDID configurations

Supports API controls for 3rd party control system via TELNET/SSH login or TCP socket connection

Supports Device Discovery “SHOW ME” function

Supports Controls/Managements in HTTP/HTTPS Web GUI

Supports image preview, point-to-point signal extension, signal distribution

Supports analog audio embedding and extracting

100M/1G Ethernet port, supporting PoE function (802.3af PD device)

Easily live stream events to popular platforms such as YouTube, Facebook, Wowza, OBS through native options in the powerful Web UI

15.6" retractable conference screens with ultra-narrow bezels

2x Inputs + 2x Outputs (Dante® in and Dante® out)

Balanced/unbalanced XLR analog audio

MIC Phantom 48V Power and on/off via a hard button

Input sensitivity and output gain control to adjust for different levels of MIC/XLR

Dante® audio sampling rate supports 44.1/48/88.2/96KHz@24bit

Configurable Dante® device latency (supports 1, ,2 or 5ms configurable using Dante® Controller)

Supports AES67 RTP audio transport

PoE & local power options

Standard 2-GANG US faceplate design

2x Inputs + 2x Outputs (Dante® in and Dante® out)

Balanced/unbalanced XLR analog audio

MIC Phantom 48V Power and on/off via a hard button

Input sensitivity and output gain control to adjust for different levels of MIC/XLR

Dante® audio sampling rate supports 44.1/48/88.2/96KHz@24bit

Configurable Dante® device latency (supports 1, ,2 or 5ms configurable using Dante® Controller)

Supports AES67 RTP audio transport

PoE & local power options

Standard 2-GANG EU/UK faceplate design

Two-channel Bluetooth audio to Dante® 2CH digital audio

Supports Bluetooth V5.1, SBC/AAC/APTX/APTX-LL/APTX-HD, up to 192KHz@24bit

Dante® audio sampling rate supports 48KHz@24bit

Dante® audio delay supports 1/2/5ms (configurable)

Supports local USB-C port power supply and PoE function (Class 0 802.3af PoE)

Compact design for easy and flexible installation

Supports Bluetooth ID renaming.

3 camera sources connection, 1x USB 3.0, 1x USB 2.0, 1x HDMI 1.4

Seamless switching between 3 input sources.

Picture in picture, side by side, big and small.

Enable mute video/audio to video conferencing or live broadcasting.

Audio I/O and mixer through the Web GUI.

BYOM (Bring Your Own Meeting), compatible with almost all USB cameras and USB conferencing audio solutions

(Bring Your Own Device),dongles, apps for Windows, macOS, Android, or via AirPlay, Miracast, and Chromecast.

Up to 4 video on display

Dual network ports for both company staff and guests.

128x MEMS microphone array

1x RJ45 Dante PoE port

Supports both sound pickup and local sound reinforcement modes

Supports 8x local pickup zones.

Supports 8 meters pickup distance

Music/ human voice adjustable

Rated power (4Ω): 100W

Rated power (70V): 60W / 30W / 15W / 7.5W

Rated power (100V): 30W / 15W / 7.5W / 3.7W

Diffusion angle: 20° vertically, 120° horizontally

1x6.5"+1x1" dome, coaxial design.

Rated power (8Ω fixed resistance): 60W (240W, PEAK)

Rated power (70V constant voltage): 20W/10W/5W/2.5W

Rated power (100V constant voltage): 40W/20W/10W/5W

Easy wiring: Front-out wiring cable raceway.

Rated power 60W

Supports Dante

Diffusion angle: 20° vertically, 120° horizontally

Supports PoE: 802.3af/802.3at/802.3bt

Sensitivity of 93dB

1x6.5"+1x1" dome

Output power of 60W

Rated power (8Ω fixed resistance): 60W

Easy wiring: Front-out wiring cable raceway.

Supports Dante

Converting Bluetooth or 2-channel RCA stereo audio into Dante

Powered by PoE and installed in a standard 86-box

Connect to mobile phones, iPad,s and other devices through the Bluetooth interface

Support Bluetooth 5.0

Support Dante and AES67.

4K Video: resolutions up to 4K60Hz 4:4:4.

4x2 conference presentation switch, integrating video, audio, USB, control and ethernet.

Dual USB-C and dual HDMI + USB Host inputs.

Full-featured USB-C inputs

GPIO, RELAY, and OCS Sensor

48Gbps FRL and 18Gbps TMDS video bandwidth

Resolution up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit

HDR, HDR10, HDR10+, Dolby Vision, HLG pass-through

Support audio de-embedding function

Support resolution auto downscaling on each output

48Gbps FRL and 18Gbps TMDS video bandwidth

Resolution up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit

HDR, HDR10, HDR10+, Dolby Vision, HLG pass-through

Support audio de-embedding function

Support resolution auto downscaling on each output

48Gbps FRL and 18Gbps TMDS video bandwidth

Resolution up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit

HDR, HDR10, HDR10+, Dolby Vision, HLG pass-through

Support audio de-embedding function

Support resolution auto downscaling on each output

Wired screen presentation via USB-C (with DP) and HDMI

Wireless BYOD via Airplay, Miracast and Dongle

Wide angle 4K video camera with 120° FOV.

2x 8W Stereo full range speakers

Auto Framing / Speaker Tracking / Presenter Tracking
