Capture video & audio from HDMI sources.
Video resolution up to 4K@60Hz 4:4:4.
HDMI loop output up to 4K@60Hz 4:4:4.
Capture video up to 4K@60Hz 4:2:0 via USB-C.
Compatible with multiple third-party applications.
Supports OBS, VLC, PotPlayer, YouTube, QuickTime.
Supports microphone input & headphone output.
Powered by USB-C, no external PSU required.
| Модель | iSwitch UVC03K (v2) |
| Имя | 4K60 HDMI to USB 3.0 Video Capture |
| Видео | |
| Вход | 1x HDMI2.0 |
| Input connector | 1x 19-pin type-A female HDMI 2.0,4K@60Hz 4:4:4 |
| Выход | 1x HDMI2.0 |
| Output connector | 1x 19-pin type-A female HDMI 2.0,4K@60Hz 4:4:4 |
| Разрешение входа HDMI | Up to 4K@60Hz 4:4:4 8bit |
| LOOPOUT Resolution | Up to 4K@60Hz 4:4:4 8bit |
| HDMI Audio Format | ПКМ 2.0 |
| Capture | 1x USB-C 3.0 |
| Output connector | 1x TYPE-C 5Gbps |
| Video Capture Format | До 4K@60Hz 4:2:0 |
| Compatible Media Player | OBS, Potplayer, VLC and so on. |
| OS Support | Windows, MacOS X, Linux. |
| USB Output Color Space | YUY2, RGB24 and NV12 |
| Аудио | |
| Вход | 1x Microphone |
| Input connector | 1x 3.5mm microphone audio jack |
| Выход | 1x Headphone |
| Output connector | 1x 3.5mm headphone audio output jack |
| Microphone Audio Format | PCM2.0 |
| Headphone Audio Format | PCM2.0 |
| Общее | |
| Рабочая температура | -5~ 55℃ |
| Температура хранения | -25 ~ 70℃ |
| Относительная влажность | 10% ~ 90% |
| Питание | 5В постоянного тока |
| Размер (W*H*D) | 102mm x 61mm x 13mm |
| Raw Materials | Железо |
