Includes one Conexión HDMI input and one USB-C inputs, with support for Auto, Manual and Priority input switching modes.
Características three Ethernet ports, any one of which can be used to transmit A/V streams, control data, and Dante audio streams.
Supports input and output resolutions up to 3840 x 2160@60Hz 4:4:4.
Soporta HDR10 y Dolby Visión.
Soporta CEC.
Soporta multi-channel audio up to PCM 7.1, Dolby Atmos, DTS HD Master and DTS:X.
Configurable audio input/output direction.
Conexión HDMI eARC audio return.
HDCP 2.2/2.3
Flexible routing of audio, video, USB, RS-232 and IR signals independently or together throughout the matrix system.
Extends audio, video, USB, RS-232, IR, and power señales hasta 328 ft (100 m) over a single Cat 5e (or higher) cable.
Soporta bidirectional RS-232
Soporta bidirectional IR passthrough for controlling remote source and display devices between encoders and decoders.
Supports IR generation, allowing IR codes to be sent through the
Soporta point-to-point, point-to-multipoint, multipoint-to-point, multipoint-to-multipoint application
Soporta PoE, allowing the device to be remotely powered by compatible power source equipment such as a PoE-enabled Ethernet switch, eliminating the need for a nearby power outlet.
Soporta DHCP by default, and falls back to Auto-IP if no DHCP server is available in the system.
Supports control via Telnet API or an IP controller (iSwitch 2000-CTL).
Supports the Telnet, SSH, HTTP, and HTTPS protocols.
Soporta 2-channel Dante transmit and 2-channel Dante receive audio streams when Dante is licensed (default: Dante unlicensed)
